AVANTI Lighting LED Tape Drivers 24V IP20

Model: AV-15-24

Features:
• Low Profile Constant Voltage Driver
• AC input: 200-240VAC
• Efficiency up to 82%
• Protections: short circuit/ over loading/
over current/ over temperature
• Full protection plastic housing easy
installation
• Cooling by free air convection
• Suitable for profile lighting and lightboxes

Output Specifications
Output Voltage: 24V
Voltage Tolerance: 250mV
Output Current: 0.625A
Rated Power: 15W

Input Specifications
Input Voltage 200-240VAC
Frequency Range 50-60Hz

Inrush Current: <70A

Full Load Efficiency (Typ.): 82%

AC Current (Max.) 0.23A

Power Factor PF >0.5/240VAC (Full Loading)

Protection
Short Circuit Shut down o/p voltage, re-power onto recover after fault condition is removed
Over Loading <120%, Shut down o/p voltage, re-power onto recover

Over Temperature 115°C shut down o/p voltage, re-power onto recover

Protection Class II

Environment
Working Temperature -20~+45°C (Refer to derating curve), +85°C (max case temp.)
Working Humidity 45 -85%

Safety & EMC

Safety standards EN613471, EN61347-2-13

EMF EN62493-2010
ERP EN1194-2012
EMS EN61000-3-2; EN61000-3-3; EN61547
Weight 0.06 Kg
Size 103 x 35.5 x 16 mm
IP Rating IP20
Packing 385 x 216 x 215 mm (200PCS/CTN)

Model: AV-30-24

Features:
• Low Profile Constant Voltage Driver
• AC input: 220-240VAC
• Built in PFC Function, Flicker Free
• Efficiency up to 86%
• Protections: short circuit/ over loading/
over current/ over temperature
• Full protection plastic housing easy
installation
• Cooling by free air convection
• Suitable for profile lighting and lightboxes

Output Specifications

Output Voltage: 24V
Voltage Tolerance: 180mV

Output Current: 1.25A

Rated Power: 30W

Input Specifications
Input Voltage 220-240VAC
Frequency Range 50-60Hz

Inrush Current <20A
Full Load Efficiency (Typ.) 86%

AC Current (Max.) 0.17A

Power Factor PF >0.9/230VAC (Full Loading)

Protection

Short Circuit Shut down o/p voltage, re-power onto recover after fault condition is removed
Over Loading <120%, Shut down o/p voltage, re-power onto recover

Over Temperature 115°C shut down o/p voltage, re-power onto recover

Protection Class II

Environment

Working Temperature -20~+45°C (Refer to derating curve), +80°C (max case temp.)
Working Humidity 10-90%

Safety & EMC

Safety standards EN613471, EN61347-2-13

EMF EN62493-2010
ERP EN1194-2012
EMS EN61000-3-2; EN61000-3-3; EN61547

IP Rating IP20

Weight 0.14 Kg
Size 123 x 44.6 x 19.2 mm

Packing 255 x 205 x 160 mm (50PCS/CTN)

Models: AV-60-24

Features:
• Low Profile Constant Voltage Driver
• AC input: 220-240VAC
• Built in PFC Function, Flicker Free
• Efficiency up to 90%
• Protections: short circuit/ over loading/
over current/ over temperature
• Full protection plastic housing easy
installation
• Cooling by free air convection
• Suitable for profile lighting and lightboxes

Output Specifications

Output Voltage: 24V
Voltage Tolerance ±5%
Output Current: 0-2.5A
Rated Power: 60WInput Specifications
Input Voltage 198-264VAC
Frequency Range 47-63Hz

Inrush Current <70A
Full Load Efficiency (Typ.) 87%
AC Current (Max.) 0.5A

Power Factor PF >0.95/230VAC (Full Loading)

Protection

Short Circuit Shut down o/p voltage, re-power onto recover after fault condition is removed
Over Loading <120%, Shut down o/p voltage, re-power onto recover

Over Temperature 115°C shut down o/p voltage, re-power onto recover

Protection Class II

Environment
Working Temperature -20~+45°C (Refer to derating curve), +85°C (max case temp.)
Working Humidity 10-90% RH

Safety & EMC
Safety standards EN61347-1:2015 EN 61347-2-13:2014+A1 EN62493:2015

Safety & EMC

EMF EN62493-2010
ERP EN1194-2012
EMS EN61000-3-2; EN61000-3-3; EN61547

Other Specifications:

IP Rating IP20
Weight 0.2 Kg
Size 170 x 44.5 x 28.2 mm
Packing 255 x 205 x 160 mm (50PCS/CTN)
